Model Number

SM4722

Power Supply

24VAC±10%；220VAC±10%

Power

50W(including air cooling HeatingAC24V);

80W(including air cooling HeatingAC220V)

Shield Outline Dimension

640(L)×188.5(W)×194(H)mm

Max. Camera/Lens Size

370(L)×125(W)×104(H)mm

Material

Body: Aluminum Alloy; Window: transparent glass; Hasp: stainless steel

Window Area

102(W)×89(H)mm

Auto Temperature Control Range

Heating(On): 8+-5degree C, (Off): 20+-5degree C(Fan running meanwhile);

Fan(On): 37+-5degree C, (Off): 20+-5degree

Protective Cover Level

IP66

Installation Environment

Indoor/Outdoor

Weight

5.0kg/5.5kg

Working Environment

-35degree C ~ +65degree C, Humidity﹤90%RH

Optional Accessories

Heater, fan, sun shade, wiper

Recommended Bracket

Wall Mounting: SM2770、SM2790
